MLI Ultra Relay and Fuse Connect Kit 111130
$517.00
RRP $579.00
SAVE $62.00 (11%)
In Stock (1
) - Dispatches in 2
days
With the MLI Ultra Relay and Fuse Connect Kit, you can easily install all the required safety accessories in a safe, efficient, and compact way right on top of the MLI Ultra battery.
Without the need for power tools, you can get your system, safe and ready in just a few simple steps.
Fast and easy installation.
- All necessary safety accessories in one kit*.
- Pre-assembled on an easy to mount bracket.
- Perfect fit for MLI Ultra 12/2750, 12/5500 & 24/5500.
* The T-fuse itself is not included in the kit. Order the right fuse rating based on the requirements of your installation.
| CODE | 111130 | 111131 | ||
|---|---|---|---|---|
| Description | Fuse Connect Kit 12V | Fuse Connect Kit 24V | ||
| General Specifications | ||||
| Compatability | MLI Ultra 12/2750 | MLI Ultra 24/5500 | ||
| MLI Ultra 12/5500 | MLI Ultra 24/5500 | |||
| Max. current | 300A | 300A | ||
| Operating temperature | -25°C to 50°C | -25°C to 50°C | ||
| Dimensions | total height increases by 65mm | total height increases by 65mm | ||
| Weight | total weight increases by 2kg | total weight increases by 2kg | ||
| Delivered with | Mounting bracket, safety relay, T-fuse holder, busbar conductor (2x) | Mounting bracket, safety relay, T-fuse holder, busbar conductor (2x) | ||
| Technical Specifications | ||||
| Safety relay | 12V DC - 500A | 24V DC - 500A | ||
| Max. voltage | 64V | 64V |
(B-P-111130)
| SKU | B-P-111130 |
