Blue Sea ST Blade Fuse Block, 6 Circuits, Neg Bus BS-5025
$81.00
RRP $109.90
SAVE $28.90 (26%)
In Stock (11
) - Dispatches in 2
days
Provides a covered, surface mount circuit consolidation and protection using ATO or ATC (blade) fuses (sold separately). Circuits all feature the same source for easy master switching. Clear insulating cover allows storage of spare fuses, and Features an easy to open, push button latch. Fuses not included.
| Code | Circuits | Negative Bus | Positive Bus | Length mm | Width mm | Height mm | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BS-5025 | 6 | #10-32 stud | #10-32 stud | 124 | 84 | 39 | ||||||
| BS-5025B | 6 | #10-32 stud | #10-32 stud | 124 | 84 | 39 | ||||||
| BS-5026 | 12 | #10-32 stud | #10-32 stud | 164 | 84 | 39 | ||||||
| BS-5026B | 12 | #10-32 stud | #10-32 stud | 164 | 84 | 39 | ||||||
| BS-5028 | 6 | - | #10-32 stud | 93 | 84 | 39 | ||||||
| BS-5028B | 6 | - | #10-32 stud | 93 | 84 | 39 | ||||||
| BS-5029 | 12 | - | #10-32 stud | 132 | 84 | 39 | ||||||
| BS-5029B | 12 | - | #10-32 stud | 132 | 84 | 39 |
(B = Bulk, No packaging)
Consolidates branch circuits and in-line fuses
- Positive distribution bus with #10-32 stud
- Can be used for 24-hour circuits
- Models available with or without a cover
- Cover satisfies ABYC/USCG requirements for insulation, incorporates an easy to open push button latch providing easy access to fuses, storage for two spare fuses, and label recesses that accept Blue Sea Systems" Small Format Labels for circuit identification
- Fuse blocks with covers include 20 write-on circuit labels
- Tin-plated copper buses and fuse clips
- Accepts ring or snap fork type terminals
- Accepts ATO® and ATC® fast acting blade fuses
- Fuses sold separately
Accessories
BS-8214 Label Set
(B-P-BS-5025)
| SKU | B-P-BS-5025 |
| Brand | Blue Sea Systems |
